Hook-type lifting ring DSH

Rated 0 out of 5
(0 customer reviews)

In stock

Standard metric and UNC threads available:
M 8 to M 20 – WLL from 0.40 t to 2.50 t
UNC 5/16″ to UNC 3/4″ – WLL from 1,000 lbs to 5,250 lbs
Safety factor
5:1
Complies with the Machinery Directive
2006/42/CE
Manufactured in compliance with the
EN 1677-1 norm
Individual traceability number

Description

The double swivel hook DSH combines a swivel lifting ring and a hook in one piece. It is composed of a steel lifting ring, has a rotating range of 360° and is equipped with a self-locking latch for maximum safety. The universal safety hook DSH is compatible with all fastening systems: textile slings, chains, cables, lugs… Hooking is done quickly and is compatible with any type of strand.

The DSH lifting ring carries various markings, including CE, WLL and tightening torque. It is manufactured in compliance with the REACH regulation.
